Information
Control (Manual or CNC):
CNC
Availability:
Build to Order
Location:
Wuxi
Jiangsu
China
Specifications
Tonnage:
1,000T / 907.2 t
OA Length:
20.47 ' / 6.2 m
OA (Overall) Length:
245.669 " / 6,240mm
BH (Between Housings):
188.976 " / 4,800mm
Description
Type Hydraulic CNC electro-hydraulic synchro
Working force 1000 T
Length of table 6000 mm
distance between frames 4800 mm
Throat depth 750 mm
Open height 900 mm
Stroke 400mm
Strokes 1.5 /min-1
Main motor 55kw
CNC system Type: DELEM 56
Delem Co., Netherlands
3 Axis(Y1,Y2, X) + Automatic compensation system.
Tool With 1 punching and 1 bottom die
Main Electric Elements in cabinet Schneider or Siemens
Seal in the cylinders NOK, Japan
Seller Information
Address:
Wuxi
China
Phone:
(+86) 86-510-8-321-1539
Fax:
(+86) 86-510-8-320-2944
Jinwei Song (sales contact)
Jinwei Song (sales contact)
Mobile: (+86) 86-1596-178-2150
|
Additional Brakes, Presses
