Information
Location:
Jingjiang
Jiangsu
China
Dimensions
1200*520*1500 mm
Description
Punching Pressure (T) 40
Max. Shearing Thickness (mm) 8
Strength of Steel Plates (N/mm²) ≤450
Angle of shearing 7°
Flat Bar (H*W) (mm) 8*200
Ram Stroke (mm) 60
Number of Stroke (times/min) 10
Throat Depth (mm) 175
Punching Thickness (mm) 8
Max. Diameter of Punching (mm) 20
Main Motor Power (KW) 3
Overall Dimension (L*W*H) (mm) 1200*520*1500
N.W. 800
Seller Information
Address:
Jingjiang, Jiangsu
China
Phone:
(+86) 5238-450-9610
Coco Wang (sales contact)
Mobile: (+86) 1526-103-1350
|
Additional Ironworkers
