CATALOGUE SPECIFICATIONS:

Swing Over Table, Maximum.............................. 24-1/2"
Swing Inside Coolant Splash Guard, Maximum............. 20"
Table Longitudinal Travel.............................. 20"
Table Longitudinal Feeds, Variable..................... 0-18 FPM
Grinding Stroke, Maximum............................... 16"
Wheelhead Cross-Sliding Travel......................... 1-1/2"
Angular Adjustment of Workhead......................... 90 Degrees
Maximum Clearance Cross Slide Face to Spindle Flange .. 30"
Workhead Longitudinal Travel............................ 12"
Workhead Cross Travel.................................. 17"
Workhead Speeds, Variable.............................. 0-500 RPM
Wheelhead Motor, Horsepower............................ 5 HP
Workhead Motor, Horsepower............................. 1-1/2 HP
Hydraulic Motor, Horsepower............................ 1/2 HP
Coolant Motor, Horsepower.............................. 1/4 HP
Approximate Machine Dimensions......................... 91"x96"
Approximate Machine Height............................. 75"
Approximate Machine Weight............................. 7,000 LBS
