MANUFACTURED IN 2000
SERIAL NUMBER: 0082

MAX TURNING DIAMETER................................................ 11.81"
MAX SWING.......................................................................... 19.67"
DISTANCE BETWEEN SPINDLES....................................... 60"
SPINDLE DRIVE MOTOR..................................................... 30 HP.(EACH SPINDLE)
BAR CAPACITY..................................................................... 2.75"
NUMBER OF SPINDLES....................................................... 2
SPINDLE NOSE...................................................................... A2-8
SPINDLE BORE...................................................................... 3.15"
SPINDLE SPEED.................................................................... 3500 RPM
TURRET STATIONS............................................................... 12 + 12
SIMULTANEOUS CUTTING EACH TURRET
WEIGHT....................................................................................24,000LBS.

EQUIPPED WITH:
OSP U100 CNC CONTROLS
(2) 10" HYDRAULIC CHUCKS
(1) 12" HYDRAULIC CHUCK
MISC TOOLHOLDERS (8)
BAR FEED INTERFACE (both sides)
NC TURRET
TOOL LIFE MANAGEMENT
SERVO LINC SPINDLE
SERVO LINC NC
CHIP CONVEYOR
COOLANT TANK & PUMPS
