GANESH GMV5مطاحن العمودي

بطاقة الهوية
363250
علامة تجارية
موديل
حالة
الجديد في المخزن
السنة
2018
الموقع
California
الولايات المتحدة الامريكية
الثمن
Gmv 5 jan 2017
صور ( 4 )

التنزيلات

GANESH GMV5 (3 MB )

بطاقة الهوية
363250
علامة تجارية
موديل
حالة
الجديد في المخزن
السنة
2018
الموقع
California
الولايات المتحدة الامريكية
الثمن

الوصف

Ganesh Heavy duty knee type milling machine GMV-5 - (12”X 58”) Heavy-Duty Class-7 Super Precision Fafnir Spindle Bearings 5-Horsepower Variable Speed Head 60 – 3,600 RPM Spindle Speeds Square Box Ways on Knee & Column - Y & Z Axis Automatic Lubrication of Ways and Leadscrews 1.5-Horsepower Knee Power-Feed Motor Hard-Chrome Plated Quill 40-Taper Spindle 1-Year machine warranty, parts & labor The factory installed NEWALL DRO’s feature a 3-year no-fault warranty. Ganesh “30-day Full-Satisfaction Guarantee” based on normal usage! Note: Satisfaction guarantee does not cover freight, rigging, installation cost, machine crashes or abuses. Ask us about our smaller knee mill models or visit www.ganeshmachinery.com

المواصفات

تحويل المواصفات للمتري
الجدول-W
12 "
الجدول-L
58 "
مجال الحركة الطولية
38 "
مجال الحركة القطعية
15.75 "
القدرة
5 hp
RPM
3600 rpm
انحناء
40 Taper Spindle
الوزن
3,850 lbs

TABLE –
Table Size: 12” X 58” (305mm X 1473mm)
Table Travel / (With Power Feed) 36” (914mm) / 32” (812mm)
Table Weight Capacity 1500 lbs
T-slot width (3 Ground T-Slots) 5/8” ground reference edges (15.9mm wide)
MACHINE TRAVELS & CAPACITY –
Table Travel – X Axis / (With Power Feed) 38” (965mm) / 35” (890mm)
Cross Travel – Y Axis 15.75” (400mm)
Knee Travel – Z Axis 16” (406mm)
Ram Travel 17.7” (450mm)
Spindle Nose-to-Table Travel 2” – 18” (50 - 457mm)
Quill Travel – Manual & Power Feed 5” (127mm)
Quill feeds – With Trip Release 0.0015”, 0.003”, 0.006”, (0.038mm, 0.076mm, 0.152mm)
Quill Diameter 4.13” (105mm)
Leadscrews with ground pitch (X & Y) 200” per rev. (5mm) (ballscrews optional)
Adjustable scale ring resolution 0.001” (0.0254mm)
Slide Ways Hardened & Ground
X-Axis – Longitudinal Table Travel Hardened & ground dovetail ways
Y-Axis - Cross Slide to Knee Hardened & ground square box ways
Z-Axis - Knee to Column Hardened & ground square box ways
SPINDLE HEAD –
Head tilt (Left-to-Right) 90 – 0 – 90 degrees
Head tilt (Front-to-Back / Up-Down) 45 – 0 – 45 degrees
Head Swivel 360-degrees
Spindle Motor 5-HP, 3-Phase 208–240 vac
Spindle Taper 40-taper
Spindle Runout 0.0002” maximum runout (0.005mm)
Spindle Bearings Fafnir ABEC-7 matched set of Class-7 bearings
Variable Speed Drive - Dual Range 70 - 460 rpm (low-range) / 460 - 3600 rpm (high-range)
Note: 5,000-RPM Spindle available w/ the optional AC Inverter Spindle Head
DIMENSIONS & WEIGHT –
Power Requirements 3-Phase 220 vac @ 26-amps, (440 vac optional)
Coolant Capacity 13.5-Gallons (51 liters)
Machine Weight 3,850 lbs.
