40 TON ROUSSELLE STRAIGHT SIDE DOUBLE CRANK PRESS
Model No. 4SS72
Air clutch & brake
Air counterbalance
Back geared type
Stroke: 3"
Slide adjustment: 3"
Shut height S.D.A.U.: 12"
Area of bed: 72" L-R x 22" F-B
Opening in bed: 60-1/2" L-R x 12" F-B
Area of slide: 68" L-R x 14" F-B
Distance between housings: 72"
Distance bed to gibs: 10-1/2"
Windows: 12" F-B
Floor to top of bed: 33-1/4"
S.P.M. approx.: 45
EQUIPPED WITH: Free standing control with
dual palm buttons for run
Pushbuttons for start - stop
Toggle switch for single -
continuous - normal - jog
Spring counterbalances
3 HP 1755 RPM 208/220/440/3/60 motor
Weight approx. 5500#
Overall dimensions approx. 96" L-R x 43" F-B x 113" H
Serial no. ENSA479564
Stock no. 26603
FOB ELK GROVE VILLAGE, IL
