WEBSTER & BENNETT 48Mعمودي مملة ميلز (incld VTL)

بطاقة الهوية
400385
علامة تجارية
موديل
السنة
1967
الموقع
Ohio
الولايات المتحدة الامريكية
رقم المخزن
10465
نطاق السعر
$10,001 - $50,000 USD

الوصف

48" WEBSTER & BENNETT VERTICAL TURNING & BORING MACHINE, MODEL M, See VIDEO T.R. Wigglesworth Machinery Company has specialized in the Webster & Bennett line of Vertical Turning & Boring Machines for over 70 years. From stocking the new line of Webster & Bennett Machines in our Bedford warehouse, to rebuilding machines, our staff has accumulated a tremendous amount of knowledge and experience over the years. Today our company continues to support owners of Webster Bennett VTL’s by providing OEM parts, Reclaimed parts and both New & Used accessories and manuals.

المواصفات

تحويل المواصفات للمتري
قطر المنضدة
48 "
الأرجحة
59 "
ارتفاع الشغل U/R
24 "
RPM
100 rpm
الأبعاد
89" X 115" X 131" TALL
الوزن
18000

ONE (1) USED
48" WEBSTER & BENNETT VERTICAL TURNING & BORING MACHINE

MODEL: M
NEW: 1967

SPECIFICATIONS:
DIAMETER OF TABLE..................... 48"
MAXIMUM SWING......................... 59"
MAXIMUM DISTANCE UNDER CROSS RAIL..... 24"
MAXIMUM DISTANCE UNDER TURRET......... 35"
VERTICAL TRAVEL OF TURRET............. 26"
SWIVEL OF TURRET HEAD................. 35 DEGREES L OR R TABLE SPEEDS (12)..................... 4.5 - 100 RPM FEED RATES (12)....................... 0.005 - 0.250 IPR DIAMETER OF TURRET HOLES.............. 3"
APPROX. WEIGHT........................ 18000 LBS APPROX. DIMENSIONS.................... 89" X 115" X 131" TALL

EQUIPPED WITH:

48" 4-JAW CHUCK
4-HEAVY DUTY JAWS
HEAVY DUTY FABRICATED CHIP GUARD
FIVE POSITION TURRET
5) BOX TYPE TOOL HOLDERS
MOTOR GUARD
30 HORSE POWER MAIN DRIVE MOTOR

SPECIFICATIONS SUBJECT TO VERIFICATION
