PINNACLE MACHINE TOOL BX-500مراكز التجهيز العمودي (5 محور أو أكثر)

بطاقة الهوية
408810
علامة تجارية
موديل
حالة
الجديد في المخزن
السنة
2017
الموقع
تايوان
عودة السياسة
30 يوم
رقم المخزن
3450
الثمن

الوصف

This Pinnacle 5 axis BX-500 has a Patented Design that delivers more accuracy, rigidity and the largest work envelope for the foot print. only the finest components go into these machines. Call or write for more info and a demo

المواصفات

تحويل المواصفات للمتري
X
51.18 "
Y
24.01 "
Z
24.01 "
أكسات
5
القدرة
20 hp
RPM
15000 rpm
# ATC
30
انحناء
BT 40 Taper
الأبعاد
133" x 87" x 122"
الوزن
16,000 Lbs.
CNC تحكم
CNC (Heidenhain iTNC530 Smart)

Pinnacle BX-500 Heidenhain, Machining center, 5- Axis Simultaneous with Heidenhain TNC640 Control

Manufacturer: Pinnacle
Model: BX-500
S/N:
Year:2017
Condition: New with 2 year Warranty

Specifications:

TABLE
Table Size 57.08" x 24.01"
Travel Range (X) 51.18"
Travel Range ( Y) 24.01"
Travel Range (Z) 24.01"
Max Table Load 1,874 Lbs.
Spindle Nose to Table Surface 4.33" - 28.34"
T-Slot .7" x 4.92" x .19"

BUILT-IN SPINDLE
Spindle Taper BT 40
Bearing Inner Diameter 2.75"
Spindle Center to Column 26.57"
Spindle Speed 15,000 RPM
Draw Bar Force 900+ 100
Main Motor ( con/ 30 min) 20HP/ 24 HP
Motor Type Indramat 1 MB 160F-4B
Motor Torque ( Con/ Max Nm) 48/120

SWING HEAD
Driver Type Worm Gear
Reduction ratio 1 : 72
Tilting Range 120 degrees
Max. Speed (rpm) 25 RPM
Clamp Torque 1157
Working Torque ( Nm ) 764

ROTARY TABLE
Type Embedded
Drive Type Direct Drive
Table Diameter 19.68"
Center Bore Diameter 1.96"
Rotation Speed 50 RPM
Min. Index 0.001
Max. Table Load 1,102 Lbs.

AXIS SERVO MOTORS
Rapid Feed Rate ( X/Y/Z ft/min) 1416/1416/936 IPM
Feed Rate ( X/Y/Z Inches/min) 394 IPM
Rated Torque (X/Y/Z ft/Nm) 36'/36'/36'
B-Axis Rated Torque 36'
C-Axis Rated Torque 1033'

TOOL MAGAZINE
ATC Type Plate
CAM Type Dual Arm
Tool Selection (Bi-direction) Random
Tool Storage Capacity 24 (32/40)
Max Tool Diameter 3.5" (2.9")
Max Tool Length 9.8"
Max Tool Weight 8

ACCURACY
Positioning XYZ Linear Axis .00019"
BC Rotary (sec) 15"/10"
Repeatability XYZ Linear Axis .00011"
BC Rotary (sec) 10"/8"

MISCELLANEOUS
Air Requirement (kg/cm) 6
Voltage 220/440 volt, 3 phase
Power Requirement(KVA) 40
Coolant Tank Capacity 80 Gallons
Machine Weight 15,873 Lbs.
Machine Height 122"
Floor Space 133" x 87"
Packing Size 135" x 90" x 100"

Optional
TOUCH PROBE + RECEIVER + CALIBRATION BALL $12,880.00 INCLUDED, N/C
CTS + 20 BAR PUMP & TANK 71.6 Instead of 48 Nm $27,968.00
CTS + 20 BAR PUMP & Tank $9,936.00
CHAIN TYPE 40 - TOOL ATC $9,900.00
CHAIN TYPE 60 - TOOL ATC $21,000.00
HEIDENHAIN LINEAR SCALES FOR XYZ AXIS $13,432.00 INCLUDED, N/C
OIL SKIMMER $496.80

Warranty Machine and control, Parts and Labor 2 Years

Terms
Terms: 30% Down to Place Order - 50% by Irrevocable LC at Site Before Shipment
Balance Due 20% - Net 10 After Delivery

Equipped With:
HEIDENHAIN iTNC 640 SMART+ 15”COLORFUL TFT, + HR410 ELECTRONIC HANDWHEEL
Kinematics, DCM & TCPM software,
3 Axis heidenhain linear scales, Touch probe & calibration ball,
ROLLER LINEAR GUIDEWAYS ON 3 AXES
METAL CHIP COVER FOR 3 AXES
COOLING SYSTEM
WORKING LAMP, X/Y/Z OIL THROUGH BALLSCREW
AUTO LUBRICATION SYSTEM
OPERATION STATUS LIGHT
SPINDLE OIL COOLER, FLUSHING SYSTEM
FULL SPLASH GUARD WITH ROOF
CHAIN TYPE CHIP CONVEYOR
ARM TYPE 30-TOOL ATC
B & C AXIS WITH ENCODER,

Pinnacle BX-500 Vertical Machining Center with Built in Rotary Table, and 5-Axis Machining, Simultaneous 5 Axis

F.O.B.: Elk Grove Village, IL

PRICE …………………. $380,000.00

Movie Link: VIDEO: Click the following link or copy and paste to your browser:
https://www.youtube.com/watch?v=za1zAEkWCbs

Brochure Link:
http://www.myerstc.com/pinnacle/en/products_BX700.html
