AMADA VIPROS 358 KINGبرج اللكمات

بطاقة الهوية
414469
علامة تجارية
موديل
حالة
مستعملة - جيد
السنة
2001
الموقع
الهند
رقم المخزن
IN-PUN-AMA-2001-00001

الوصف

This AMADA Vipros 358 King Turret Punching Machine was manufactured in 2001 and has a working record of 43200 production hours ever since. Operated through an AMADA AMADAN 04P-C control unit, this full-size machine offers low maintenance costs and its spare parts are easily available. In the past, this AMADA punching machine has handled mostly mild steel of up to 3 mm in thickness and produced control panels for various industries. Several pieces of additional equipment are included: a chiller, a hydraulic tank, one set of tools and a light guard.

المواصفات

تحويل المواصفات للمتري
حمولة
33 T
محطة تارت#
58
CNC تحكم
CNC (AMADA 04PC)

AMADA Vipros 358 King Turret Punching Machine

Production Hours: 43200

General Data:
Measurements width: 4120 mm
Measurements depth: 4580 mm
Measurements height: 2450 mm
Machine weight: 16000 kg

Control Unit:
Brand: AMADA
Model: AMADAN 04P-C

Main Drive:
Punching force: 300 kN
Maximum sheet thickness: 6 mm

Movement:
X-Axis Movement: 1270 mm
Y-Axis Movement: 2032 mm

Table:
Max punching diameter: 110 mm

Tools:
Number of index: 4
Number of station: 58
Max tool diameter: 110 mm

Max Material Thickness:
Steel: 6 mm
Stainless steel: 3 mm
Aluminium: 2 mm

Media:
Main electronic connection: 400 V
Power consumption: 24 kVA
Air pressure: 6 bar

Additional Equipment:
* Chiller
* Hydraulic tank
* Toolset
* Light guard
