CITIZEN M20نوع السويسري الآلي وآلات برغي

بطاقة الهوية
417575
علامة تجارية
موديل
السنة
1995
الموقع
الولايات المتحدة الامريكية
رقم المخزن
469043

المواصفات

تحويل المواصفات للمتري
قطر ثقب عامود الدوران
0.75 "
RPM
7200 rpm
القدرة
5 hp
أكسات
8
الأبعاد
93" x 43" x 63"
الوزن
3600 (LBS)
CNC تحكم
CNC (MITSUBISHI)

CITIZEN M-20
NEW: 1995

SPECIFICATIONS:

MAX MACHINING DIAMETER.................. 0.787"
MAX LENGTH PER CHUCKING................. 12.6"
MAX DRILLING/THREADING.................. 0.315 (MB)
MAIN SPINDLE SPEEDS..................... 200 - 8,100 RPM
MAIN SPINDLE INDEXING................... FULL C-AXIS
BACKWORKING SPINDLE SPEED............... 7,200 RPM
MAIN SPINDLE MOTOR...................... 5 HP / 3 HP
ROTARY TOOL GANG PLATE SPEED............ 250 - 5,000 RPM
TURRET LIVE TOOL SPEED.................. 320 - 6,300 RPM
BACKWORKING SPINDLE CHUCKING DIAMETER... 0.787"
BACKWORKING MACHINING LENGTH............ 4.92"
BACKWORKING DRILLING/THREADING.......... 0.315 (MB)
NUMBER OF GANG TOOLS.................... 3 LIVE, 5 FIXED
NUMBER OF TURRET TOOL POSITIONS......... 10
NUMBER OF TURRET INDEXING POSITIONS..... 10 (20 AVAILABLE)
APPROX MACHINE WEIGHT................... 3,600 LBS
APPROX MACHINE DIMENSIONS............... 93" X 43" X 63"

EQUIPPED WITH:

MITSUBISHI 8-AXIS CNC CONTROL (7-CUTTING/1-POSITIONING)
MAIN / PICKOFF SPINDLE SYNCHRONIZATION
SYNCHRONIZED TAPPING
CANNED DRILLING CYCLES
MILLING INTERPOLATION
INCH-METRIC CONVERSION
CONSTANT SURFACE SPEED CONTROL
TOOL NOSE RADIUS OFFSET
MULTI REPETITIVE CYCLE 2
CHAMFERING CORNER RADIUS 1
CHAMFERING CORNER RADIES 2
DOOR LOCKS
IEMCA GENIUS 120 BAR LOADER
MIST BUSTER
COOL BLASTER BCB-CBHD11-208-1-420 HIGH PRESSURE PUMP, 4 LINE

TOOLING INCLUDED IN SALE (EST. $40,000 IN VALUE):

- (1) RIGHT ANGLE LIVE MILLING HOLDER
- (1) RIGHT ANGLE LIVE FACE DRILL HOLDER
- (1) RIGHT ANGLE LIVE SLOTTING HOLDER
- (1) ANGLE HOLDER - MODEL MSA103
- (4) X-AXIS LIVE TOOLS CROSS DRILL HOLDERS FOR TURRET
- (3) ID SINGLE SLEEVE STATIC TOOL HOLDERS
- (3) ID DOUBLE SLEEVE STATIC TOOL HOLDERS
- (6) TURNING TOOL HOLDERS
- (16) 0136 MISC.

** IN PLANT, UNDER POWER, AVAILABLE FOR IMMEDIATE INSPECTION & PURCHASE

***** MACHINE PRICE JUST REDUCED ***

***** LOCATED IN SAME SHOP: (2) CITIZEN L20 (2000) AND (1) CITIZEN L(3)20
***** PACKAGE PRICING AVAILABLE ON ALL FOUR MACHINES
