AMADA VIPROS 357 QUEENبرج اللكمات

بطاقة الهوية
424210
علامة تجارية
السنة
1997
الموقع
الولايات المتحدة الامريكية
رقم المخزن
6305

الوصف

Used Amada Turret Punch Press, Vipros 357

المواصفات

تحويل المواصفات للمتري
حمولة
33 T
محطة تارت#
58
CNC تحكم
CNC (FANUC O4PC)

EQUIPPED WITH
Built-in Microprocessor - Standard software included for programming a comprehensive set of patterns used in punching, nibbling, and notching operations.

Diagnostic System - Extensive diagnostic system indicates programming errors and pinpoints machine and control malfunctions.

Stripping Sensor - Automatically halts machine operation if tool does not strip.

Automatic Repositioning - Heavy duty work holders secure material during repositioning.

Hydraulic Drive System

Metric or inch dimensional programming.

Precision ground recirculating ball lead screws for X and Y Axis.

Crash proof clamp sensors.

Hardened and ground turret index pins and bushings.

Safety interlocks and overrun protectors with all step control prevents accidents.

58 station turret for thick tooling. (2 Auto Index Stations).

BrushTables

Fanuc 04PC control with software for pattern forming, beading, extruding and embossing with dwell cycle program at bottom of stroke

Adj. Forming Capabilities

Variable Ram stroke patterns for maintaining 75 dba in thick material

Chiller Unit

Air Blow


SPECIFICATIONS
Capacity: 33 tons
Sheet Size: 50" x 72"
Max Material Thickness: .250"
Max Hole Diameter: 4.5"
Number of Turret Stations: 58 with A/I
Hit Rate X/Y .079pitch,.118" stroke: 520/420 HPM
Hit Rate .315" pitch, ,315 stroke: 275/275 HPM
Hit Rate 1" centers .315 stroke: 275/240 HPM
Positioning Speed: 2000 IPM
Max Forming: 1/2" Flange
Control Model: Fanuc 04PC
Drive motors: AC Servo
Smallest Programmable Increment: .001"
Power Requirements: 230/460/60/3 phase
Machine Weight: 29,000 lbs
:
:
:
