سن تروسFELLOWS 70-15

Michigan, الولايات المتحدة الامريكية

نظرة عامة

علامة تجارية
موديل
بطاقة الهوية
434646
النوع
حالة
تستخدم - ممتاز
السنة
1973
الموقع
Michigan
الولايات المتحدة الامريكية
رقم المخزن
23037
الوصف
FELLOWS 70-15 GEAR SHAPER Machine Main Base With Work-table, Upper Column, Cutter Ram and Slide of "Super Robust" Construction, * Machine with "Saddle Backoff" Method of Cutter Relieving, * Cutter Spindle 6.25" diameter w/Standard Straight Spur Guide, * Cutter Positioning via Stroke Jog-Button, * Rapid Rotation of Work Spindle for Trueing Work-Piece, * Rapid Saddle Traverse for Traversing Saddle Relative to Work, * Automatic Depth Feed Mechanism for One to Four Cuts, With 4 Speed Motor, Providing Speed Change on Finishing Cut, * Assorted Work and Feed Change Gears, * Assorted Stroke Change Gears, * 2" Riser Plate
المواصفات
الأبعاد192" X 144" X 150"H
الوزن95,000 LBS

ورقة المواصفات

Model 70-15 Fellows heavy duty vertical gear shaping machine , suitable for the manufacture of external straight spur gears up to 70" pitch diameter, as well as internal spur gears and splines within a range of 0" to 88" pitch diameter, regardless of shaper-cutter radius. This unique feature, combined with the machines 15" face-width capacity and 1.7DP cutting capability in steel, provide a formidable platform for producing a wide range of larger geared part members. EQUIPPED WITH: * Machine Main Base With Work-table, Upper Column, Cutter Ram and Slide of "Super Robust" Construction * Machine with "Saddle Backoff" Method of Cutter Relieving * Cutter Spindle 6.25" diameter w/Standard Straight Spur Guide * Cutter Positioning via Stroke Jog-Button * Rapid Rotation of Work Spindle for Trueing Work-Piece * Rapid Saddle Traverse for Traversing Saddle Relative to Work * Automatic Depth Feed Mechanism for One to Four Cuts, With 4 Speed Motor Providing Speed Change on Finishing Cut * Assorted Work and Feed Change Gears * Assorted Stroke Change Gears * 2" Riser Plate * Main Drive Motor 15HP, 650/220 rpm, 240 Volt 60Hz w/Westinghouse Rectifier Unit for AC * Power Forced Lubrication to Working Elements with "Lubriquip Lub Controller" * Coolant Tank, Pump, and Piping, With Chip Pan * Full Complement of Electrics * Assorted Guards, Covers * 84" T-Slotted Table * Hydraulic System * Work Lamp * Work Platform * Cutter Adaptor * Manuals SPECIFICATIONS: Max. Diameter External Gear Cut (Nominal): 70" Max. Diameter Internal Gear Cut (Nominal): 88" Max. Diameter Workpiece Accommodated: 104" Worktable Diameter: 84" Max. Permissible Weight of Workpiece & Fixture: 36,000 Lbs. Max. Distance Workspindle Centerline to Centerline of Cutter Spindle: 35" Min. Distance Workspindle Centerline to Centerline of Cutter Spindle: 0" Max. Work & Fixture Clearance Height w/Cutter Spindle in Upper Position: 28" Max. Diametral Pitch (full length teeth): 2 DP Max. Diametral Pitch (stub teeth): .75 DP Max. Diameter Pitch (30P.A. splines): 2-5/5 DP Diameter of Cutter Spindle: 6.25" Max. Stroke Length: 19.118" Max. Face-Width (nominal): 15" Stroking Speeds (infinitely variable): 5 to 122 S.P.M. Max. Infeed of Cutter Ram: .0020 inch/min. Min. Infeed of Cutter Ram: .0005 inch/min. Max. Rotary Feed Per Stroke (per 1" of cutter diameter): .0068"/Min. Min. Rotary Feed Per Stroke (per 1" of cutter diameter): .0006"/Min. Approximate Machine Dimensions: 192"L x 144"W x 150"H Approximate Machine Weight: 95,000 Lbs
