TRAUB TNC 42مخارط CNC

بطاقة الهوية
434918
علامة تجارية
موديل
النوع
حالة
مستعملة - جيد
السنة
2003
الموقع
إيطاليا
رقم المخزن
IT-TUR-TRA-2003-00001

الوصف

This 2003 TRAUB TNC 42 Lathe was manufactured in Germany and has been operative for 42050 hours since then. Operated through a TRAUB System TX 8H Control unit, this machine has mainly worked with stainless steel up to 7mm of thickness in the past. Several additional equipment is included in the delivery.

المواصفات

أكسات
3
ماكس RPM
5600 rpm
CNC تحكم
CNC (TRAUB TX8H)

TRAUB TNC 42 Lathe

Production Hours: 42050

General Data:
Measurements width: 4250 mm
Measurements depth: 2800 mm
Measurements height: 1917 mm
Machine weight: 4800 kg

Control Unit:
Brand: TRAUB
Model: System TX 8H

Main Drive:
Number of spindles: 2
Spindle speed range: 5600 1/min

Movement:
X-Axis Movement: 140 mm
Y-Axis Movement: ±35 mm
Z-Axis Movement: 450 mm

Workpiece:
Workpiece drm: 192 mm
Workpiece X: 140 mm
Workpiece Y: 450 mm

Turret:
Number of turrets: 2

Media:
Main electronic connection: 400 V / 50 Hz
Power consumption: 18.5 kWA
Chip conveyor: Yes
Internal cooling: Yes

Additional Equipment:
* 33 tool holders Capto (Sandwik)
* 1 motorized (Traub)
* 2 hidraulic clamps (Hainbuch)
* 1 self-centering tool (Rohm)
* 1 clamp holder (Hainbuch)
* 1 workpiece chucks (Schunk)
* High pressure pump
