TRAUB TNC 42مخارط CNC

بطاقة الهوية
434920
علامة تجارية
موديل
النوع
حالة
مستعملة - جيد
السنة
2004
الموقع
إيطاليا
رقم المخزن
IT-TUR-TRA-2004-00001

الوصف

This TRAUB TNC 42 Lathe from 2004 was manufactured in Germany and has a working record of 41067 production hours. Equipped with a TRAUB System TX 8H, this efficient machine stands out for its 2 spindles working up to 5600 rpm. Tool holders, hydraulic clamps and a high pressure pump are some of the several additional tools included with the machine.

المواصفات

أكسات
3
ماكس RPM
5600 rpm
CNC تحكم
CNC (TRAUB TX8H)

TRAUB TNC 42 Lathe

Production Hours: 41067

General Data:
Measurements width: 4250 mm
Measurements depth: 2800 mm
Measurements height: 1917 mm
Machine weight: 4800 kg

Control Unit:
Brand: TRAUB
Model: System TX 8H

Main Drive:
Number of spindles: 2
Spindle speed range: 5600 1/min

Movement:
X-Axis Movement: 140 mm
Y-Axis Movement: ±35 mm
Z-Axis Movement: 450 mm

Workpiece:
Workpiece drm: 192 mm
Workpiece X: 140 mm
Workpiece Y: 450 mm

Turret:
Number of turrets: 2

Media:
Main electronic connection: 400 V / 50 Hz
Power consumption: 18.5 kWA
Chip conveyor: Yes
Internal cooling: Yes

Additional Equipment:
* 33 tool holders Capto (Sandwik)
* 1 motorized Traub
* 2 hidraulic clamps (Hainbuch)
* 1 self-centering tool (Rohm)
* 1 clamp holder (Hainbuch)
* 1 workpiece chucks (Schunk)
* 1 high pressure pump
