AMADA LC1212A2قاطعات الليزر

بطاقة الهوية
435039
علامة تجارية
موديل
السنة
1998
الموقع
New York
الولايات المتحدة الامريكية
رقم المخزن
11266

المواصفات

تحويل المواصفات للمتري
ورقة-W
4 '
ورقة-L
8 '
وات
2000 w
حركة X
50 "
حركة Y
50 "
حركة Z
11.8 "

AMADA PULSAR LC1212A2, 2000 WATT, MFG:1998 Our stock number: 11266

1.1 Motion System Specifications:
Max. Sheet Size: 4' x 8'
X-Travel: 50"
Y-Travel: 50"
Z-Travel: 11.8"
Max. Positioning Speed: 1575 IPM
Positioning accuracy: +/- 0.0004"/20"
Work Chute: 66" x 21"
Max. Weight: 484 Lbs.
Will Cut: 1/2" Thickness in Mild Steel
Overall Dimensions: 123" x 100" x 86.5"
1.2 CNC Controller Specifications
Model: FANUC 160i-L - 32 bit
Display: LCD Color Graphics Display
Control Function: X, Y,Z, and B Simultaneous 3 Axis and B
axis Laser Power Control
Input Method: MDI, Edit, DNC or 3" PC Compatible Floppy Disk
Minimum Command Unit: 0.0001" (X, Y, Z)
Minimum Travel Unit: 0.0001" (X, Y, Z)
Standard Memory: 128K (320m)
Optional Memory: Expandable to 256K or 512K
Operating Modes: Automatic, MDI & Manual
Display Modes: Program Contents, Position Information, Program Check,
Settings, Parameters, Beam Diameter Compensation, Assist Gas Status, Self
Diagnostics
Interlock Displays Water Temperature, Gas Pressure, Vacuum Leak, Blower
Malfunction, Shutter Power, Discharge, Assist Gas, Door Open
Electrical Requirements: Included in Machine Requirements

Includes chiller and dust collector
