General Specifications for a 2006 M.S. Machining HMC-200
TRAVEL:
X Axis 78 [1981mm]
Y Axis 72" [1473.2mm]
Z Axis 58" [1473.2mm]
B Axis 360 degree
SPINDLE:
Power MTD 30hp
Speed 0-3000 RPM
Taper CV 50
INDEX TABLE:
1 degree
39" x 39" [990.6mm x 990.6mm] table top
10,000 Lbs [4536KG] Table load capacity
TOOLS:
48 tool storage standard.
50Lbs [22.7kG] capacity
Max diameter 10" [254mm] with adjacent pocket empty
PALLET CHANGER
4 stations - pallets
39" x 39" [990.6mm x 990.6mm]
GENERAL:
GE Fanuc 18i-m Control
Weight 65,000 Lbs.
Footprint 25.5' x 27.8' [7.8m x 8.5m]
