GENERAL SPECIFICATIONS

Original Swing Over Bed: 56”
Swing Over Bed (with Risers): 66”
Original Swing Over Cross Slide: 37”
Swing Over Cross Slide: 47”
Total Bed Length: 38’
Distance Between Centers: 33’
Length of First Section from Chuck Face: 18’6”
Approx Weight: 100,000 Lbs
Voltage: 230/460
Number of Sections: 2
Main Motor: 40 HP
Spindle Speed: 165 RPM
Gear Ranges: 4

INCLUDES: 40 HP Motor, 165 RPM Spindle, 2 Roller Steady Rests and Rigid Tailstock.
