New (32)
Contact GUOFENG
Displaying 32 Models
thumb

GUOFENG C5112

Max. turning diameter 1250 mm Working table diameter 1000 mm Max. weight of work-piece 3.2 T Max. height of work-piece 1000 mm Horizontal travel of vertical tool post 700 mm Vertical travel of vert...

Boring Mills, Vertical (incld VTL)
1 photo
thumb

GUOFENG C5116

Max. turning diameter 1600 mm Working table diameter 1400 mm Max. weight of work-piece 5 T Max. height of work-piece 1000 mm Horizontal travel of vertical tool post 915 mm Vertical travel of vertic...

Boring Mills, Vertical (incld VTL)
1 photo
thumb

GUOFENG C5123

Max. turning diameter 2300 mm Working table diameter 2000 mm Max. weight of work-piece 8 T Max. height of work-piece 1250 mm Horizontal travel of vertical tool post 1210 mm Vertical travel of verti...

Boring Mills, Vertical (incld VTL)
1 photo
thumb

GUOFENG C5125

Max. turning diameter 2500 mm Working table diameter 2200 mm Max. weight of work-piece 10 T Max. height of work-piece 1300 mm Horizontal travel of tool post 1310 mm Vertical travel of tool post 800...

Boring Mills, Vertical (incld VTL)
1 photo
thumb

GUOFENG C5131

Max. turning diameter 3150 mm Working table diameter 2500 mm Max. weight of work-piece 10 T Max. height of work-piece 1400 mm Horizontal travel of tool post 1610 mm Vertical travel of tool post 100...

Boring Mills, Vertical (incld VTL)
1 photo

GUOFENG C5140

Boring Mills, Vertical (incld VTL)
thumb

GUOFENG C518

Max. turning diameter of tool post 800 mm Working table diameter 720 mm Max. height of work-piece 800 mm Max. weight of work-piece 2 t Working table range of rotation speed 10-315 r/min Working tab...

Boring Mills, Vertical (incld VTL)
1 photo
thumb

GUOFENG C5225

Max. turning diameter 2500 mm Working table diameter 2250 mm Max. weight of work-piece 10 T Max. height of work-piece 1600/2000/2500 mm Horizontal travel of tool post 1400 mm Vertical travel of too...

Boring Mills, Vertical (incld VTL)
1 photo
thumb

GUOFENG C5240

Max. turning diameter of vertical tool post 4000 mm Working table diameter 2830 mm Max. height of work-piece 2000 mm Max. weight of work-piece 20 t Working table range of rotation speed 2-63 r/min ...

Boring Mills, Vertical (incld VTL)
1 photo
thumb

GUOFENG C5250

Max. turning diameter of vertical tool post 5000 mm Working table diameter 4000 mm Max. height of work-piece 2500 mm Max. weight of work-piece 30 t Working table range of rotation speed 0.85-25.4 r...

Boring Mills, Vertical (incld VTL)
1 photo
thumb

GUOFENG C5263

Max. turning diameter of vertical tool post 6300 mm Working table diameter 4500 mm Max. height of work-piece 3150 mm Max. weight of work-piece 50 t Working table range of rotation speed 0.56-22.25 ...

Boring Mills, Vertical (incld VTL)
1 photo

GUOFENG C5263Q

Boring Mills, Vertical (incld VTL)
thumb

GUOFENG C5280

Max. turning diameter of vertical tool post 8000 mm Working table diameter 7100 mm Max. height of work-piece 3150 mm Max. weight of work-piece 50 t Working table range of rotation speed 0.25-25 r/m...

Boring Mills, Vertical (incld VTL)
1 photo

GUOFENG C5280Q

Boring Mills, Vertical (incld VTL)
thumb

GUOFENG C61200B

Max. swing diameter over bed 2000 mm Max. swing diameter over carriage 1700 mm Max. length of work-piece 10000/16000 mm Height of center 1050 mm Max. weight of work-piece 65 t Steps of the spindle ...

Lathes, Engine
1 photo
thumb

GUOFENG C61250B

Max. swing diameter over bed 2500 mm Max. swing diameter over carriage 2200 mm Max. length of work-piece 10000/16000 mm Height of center 1280 mm Max. weight of work-piece 75 t Steps of the spindle ...

Lathes, Engine
1 photo
thumb

GUOFENG CB7740

CB7740 vertical multi-tool lathes machine Max. machining diameter 400 mm Max. swing over head 600 (Hs ¡Ü100 hours) mm Max. weight of work-piece 300 kg Max. height of work-piece 250 mm Horizontal t...

Boring Mills, Vertical (incld VTL)
1 photo
thumb

GUOFENG CB7750

Max. machining diameter 500 mm Max. swing over bed 580 mm Max. weight of work-piece 300 kg Max. height of work-piece 250 mm Horizontal travel of tool head 260 mm Vertical travel of tool head 250 mm...

Boring Mills, Vertical (incld VTL)
1 photo
thumb

GUOFENG CB7763

CB7763 vertical multi-tool lathe Max. machining diameter 630 mm Max. swing over bed 800 mm Max. weight of work-piece 500 kg Max. height of work-piece 360 mm Horizontal travel of tool head 200 mm V...

Boring Mills, Vertical (incld VTL)
1 photo
thumb

GUOFENG CK5112

Max. turning diameter 1250 mm Working table diameter 1000 mm Max. weight of work-piece 3 T Max. height of work-piece 1000 mm Horizontal travel of vertical tool post 700 mm Vertical travel of vertic...

Boring Mills, Vertical (incld VTL)
1 photo
thumb

GUOFENG CK5116

Max. turning diameter 1600 mm Working table diameter 1400 mm Max. weight of work-piece 5 T Max. height of work-piece 1000 mm Horizontal travel of vertical tool post 915 mm Vertical travel of vertic...

Boring Mills, Vertical (incld VTL)
1 photo
thumb

GUOFENG CK5123

Max. turning diameter 2300 mm Working table diameter 2000 mm Max. weight of work-piece 8 T Max. height of work-piece 1250 mm Horizontal travel of vertical tool post 1210 mm Vertical travel of verti...

Boring Mills, Vertical (incld VTL)
1 photo
thumb

GUOFENG CK5125

Max. turning diameter 2500 mm Working table diameter 2200 mm Max. weight of wok-piece 10 T Max. height of work-piece 1300 mm Horizontal travel of vertical tool post 1310 mm Vertical travel of verti...

Boring Mills, Vertical (incld VTL)
1 photo
thumb

GUOFENG CK5131

Max. turning diameter 3150 mm Working table diameter 2500 mm Max. weight of work-piece 10 T Max. height of work-piece 1400 mm Horizontal travel of vertical tool head 1610 mm Vertical travel of vert...

Boring Mills, Vertical (incld VTL)
1 photo
thumb

GUOFENG CK518

Description: 1. This series machine is suitable for machining in industries of motor,turbine, aerospace, mining as well as metallurgy, etc. 2. It can make rough and accurate turning the internal ...

Boring Mills, Vertical (incld VTL)
1 photo
thumb

GUOFENG CK5240

Max. turning diameter of vertical tool post 4000 mm Working table diameter 2830 mm Max. height of work-piece 2000 mm Max. weight of work-piece 20 t Working table range of rotation speed 2-63 r/min ...

Boring Mills, Vertical (incld VTL)
1 photo
thumb

GUOFENG CK5250

Max. turning diameter of vertical tool post 5000 mm Working table diameter 4000 mm Max. height of work-piece 2500 mm Max. weight of work-piece 30 t Working table range of rotation speed 0.85-25.4 r...

Boring Mills, Vertical (incld VTL)
1 photo
thumb

GUOFENG CK5263

Max. turning diameter of vertical tool post 6300 mm Working table diameter 4500 mm Max. height of work-piece 3150 mm Max. weight of work-piece 50 t Working table range of rotation speed 0.56-22.25 ...

Boring Mills, Vertical (incld VTL)
1 photo
thumb

GUOFENG CK5280

Max. turning diameter of vertical tool post 8000 mm Working table diameter 7100 mm Max. height of work-piece 3150 mm Max. weight of work-piece 50 t Working table range of rotation speed 0.25-25 r/m...

Boring Mills, Vertical (incld VTL)
1 photo
thumb

GUOFENG M8820K

Inside diameter of grinding work-piece 140¡«400 mm Radius of grinding raceway 0-140 mm Speed of work-piece rotation 65;100 rpm Swing frequency of working table 17;28 time/min Max. swing angle of wo...

Grinders, Bearing Race
1 photo
thumb

GUOFENG M8830

Inside diameter of grinding work-piece 140¡«400 mm Radius of grinding raceway 0-140 mm Speed of work-piece rotation 65;100 rpm Swing frequency of working table 17;28 time/min Max. swing angle of wo...

Grinders, Bearing Race
1 photo
thumb

GUOFENG Y31125E

Max. diameter of work-piece 1000/1250 mm Working table diameter 950 mm Max. modulus of wok-piece 16 mm Max. length of hob 220 mm Max. width of machining 450 mm Mandrel diameter of work-piece 60 mm ...

Gear Hobbers
1 photo
