SNK RB-7VMGantry Machining Centers (incld. Bridge & Double Column)

Photos (1)

More on this model

To view more information on the SNK RB-7VM, including brand information, photos, videos, and more, click here.

Specs

Convert Specs to Metric
X
324.8 "
Y
177.2 "
Z
23.62 "
Power
30 hp
RPM
6000 rpm
Table-W
137.8 "
Table-L
315 "
# ATC
80
Taper
BT50
Control
CNC (FANUC 18iMB)

5 Face Double column MCT
MAKER : SNK
MODEL : RB-7VM
MFG DATE : 2005
SPECIFICATIONS -
CONTROL SYS: FANUC-18iMB
Between columns : 4,100mm
TABLE SIZE : 3,500x8,000mm
STROKE : X8,250 Y4,500 Z600 W1,600mm
Distance from table top to spindle nose : 2,000mm
ATC80
BT50
SPINDLE SPEED: MAX6,000rpm
SPINDLE MOTOR : 30/22KW AAC3
(1) Extension head : 1
(2) 30 degree angle head : 1
(3) 90 degree angle head : 1
