Serial No. 11574 New - 1998 SPECIFICATIONS: Internal Diameter to be Ground............0.24" - 8" Grinding Stroke - Maximum............8" Swing Over Table............24" Swing Inside the Workpiece Guard............14" Longitudinal Travel............20" Table Speed............1.6 - 50 ft/min. Rapid Feed Rate............600 IPM Hydraulic Stroke............0.08" - 8.0" Reversals at............0.08" Stroke300/Min. Work Spindle Swivel Angle............(-5) - (+30) Degrees Work Spindle Speed............50 - 850 RPM Crossfeed Travel - Maximum............9.4" Feed Increment Diameter - Minimum............0.0001" Automatic Feed Range............0.01 - 0.16 IPM Rapid Feed Rate............200 IPM Wheel Spindle Motor............3 HP Workhead Spindle............2 HP Crossfeed Servo............0.4 HP Hydraulic Pump............3 HP Hydraulic Pump Capacity............16 Gallons Actual Dimensions............96"L X 50"W X 78"H Actual Coolant/Hydraulic System Dimensions............62"L x 46"W x 49"H Approximate Weight............6,200 Lbs. EQUIPPED WITH: Okamoto Model OH-20M, 20,000 RPM Oil Mist Lubricated I.D. Spindle Automatic Grinding Cycle Size Compensation Wheelhead, Table and Speed Setting Dials Continuous/Intermittent Feed Minimum Wheel Size Setting Repeat Dress, Interrupted Dressing and Dressing Selection Coolant System with Magnetic Separator Hydraulic System Books, Manuals, and Drawings *Preliminary Specifications Subject to Verification.
