Planer Type MillsWALDRICH SIEGEN POWERTEC 4000 AP
Baden-Württemberg, GermanyOverview
Brand
Model
ID #
492338
Condition
Used - Good
Year
1995
Location
Baden-Württemberg
Germany
Germany
Stock #
7-39559
In 2011/2012 these 2 identical machines were retrofitted and rebuilt by WALDRICH COBURG.
The milling length was extended to 14meters and an automatic changing system for table pallets was installed.
Both machines can be seen under power by prior appointment.
VIDEO: https://youtu.be/1QQV0A5vzf0
Convert Specs to Metric
| Table-W | 118.11" |
| Table-L | 354.33" |
| Height Under Rail | 177.17" |
| Distance Between Housings | 157.48" |
| Motor | 151.5 hp |
| RPM | 2,500 RPM |
| Control | CNC (SIEMENS 840 C) |
Spec Sheet
PLANER TYPE MACHINING CENTER – EACH WITH 3 PALLETS 9000 x 3000 mm:
- Tool changer with 420 tools
- Head pick-up system
- Video monitoring via camera
- High pressure lubrication unit for inner cooling 70bar
AVAILABLE HEAD UNITS:
- Fixed angle head HS800C600 105 Kw 600 long
- Fixed angle head HSD350C850 50 Kw 850 long
- Fixed angle head HSD 40C880 12 Kw 880 long
- Fixed angle head HSD 190C1000 30 Kw 1000 long
- Vertical spindle unit VS800C 105 Kw 900 long
- Universal spindle unit USIO40C 20 Kw B-axis rotatable at 1° at a time
- Angle spindle unit SO800C905 - 22,5° fix
- Angle spindle unit HSE1200CS -25° fix
- Universal spindle unit (fork milling) USP475C 75 Kw 1/2° Hirth
One additional drilling extension SE 350C plus 1 SE500C.
See more listings of this Type
WALDRICH VH-37
Planer Type Mills
INGERSOLL GANTRY
Planer Type Mills
WMW COMBINATION DOUBLE HOUSING
Planer Type Mills
INGERSOLL MASTERHEAD
Planer Type Mills
See more listings for this Brand
WALDRICH SIEGEN WSD 2300/100NCX12000
CNC Lathes
WALDRICH SIEGEN PF - F - 150
Planer Type Mills
WALDRICH SIEGEN
Roll Lathes
WALDRICH SIEGEN WST 1800
