Watch

Drilling & Tapping MachinesBAILEIGH GHD 20PFT

United States

Overview

ID #
542128
Condition
New In-Stock
Year
2022
Location
United States
Description
Achieve precision drilling and tapping from a design that includes an easy-to-read internal depth gauge, power downfeed speed selector, built-in spindle lock and calibrated fine down feed. JET backs this reliable combination drilling and tapping press with a Two Year Warranty.
Specs
Dimensions32 X 24 X 71
Weight1200

Equipped With

Easily accessible table raiser Head tilts left or right Heavy-duty design allows a variety of precision drilling and tapping applications Integrated tapping and reversing controls Large production table and T-slotted base Power downfeed speed selector

Spec Sheet

Base Dimensions (In.) 26 x 18 Base Work Table (In.) 15-1/4 x 13 Column Diameter (In.) 4-1/2 Distance Column to Spindle (In.) 10 Drilling Capacity Cast Iron (In.) 1-1/2 Drilling Capacity Mild Steel (In.) 1-1/4 Drills to Center of Circle (In.) 20 Motor (HP) 2 HP (2 Speed) , 230V, 3Ph Overall Dimensions (L x W x H) (In.) 32 x 24 x 71 Prop 65 Cancer and Reproductive Harm Quill Diameter (In.) 3 Quill Feed Manual Range of Spindle Speeds (RPM) 60, 120, 130, 230, 260, 450, 460, 800, 900, 1,500, 1,600, 3,000 Spindle Distance to Base (In.) 44-5/16 Spindle Distance to Table (Max.) (In.) 30-1/2 Spindle Taper (In. x TPI) MT-3 Spindle Travel (In.) 4-1/2 Style (Type) Geared Hea d T-Slot Centers (In.) 9 Table Size (L x W) (In.) 21-3/4 x 19-1/2 Table Travel (In.) 25-1/2 Tapping Capacity Cast Iron (In.) 15/16 Tapping Capacity Mild Steel (In.) 15/16 Weight (Lbs.) 708 Work Table Weight Capacity (Lbs.) 275
About the Seller
Price
$6,859.00 USD

$6,859.00 USD

More on this model

To view more information on the BAILEIGH GHD 20PFT, including brand information, photos, videos, and more, click here.
