CUBIC STS-27CNC 선반

ID#:387215
상표:CUBIC
모델:STS-27
형태:CNC 선반
년도:2012
위치:미국
가격:

투기

Lower:27
척크기:4 "
바 용량:1.06 "
#축:3
동력:3 hp
최대 RPM:6000 rpm
터닝 직경:3.15 "
스윙:5.902 "
Upper:47
가공 길이:8.661 "
심 압대:No
라이브 공구:No
치수:79" x 47" x 66"
무게:3,030 lb
제어반:CNC (Mitsubishi E60)

Chuck Size 4"
Max Diameter Bar Capacity 1.06"
Max Swing Over Bed / Carriage 5.9"
Max Turning Diameter 3.15"
Max Machining Length 8.66"
Spindle Speed 100 - 6000 RPM
Spindle Bore 1.06"
Spindle Nose A2-5
Spindle Motor 3 HP
Tools 8
Sub Spindle Chuck Size 4"
Sub Spindle Motor 4 HP
Sub Spindle Speed 100 - 6000 RPM
Rapid Traverse Rates (X & Z) 708 IPM
X-Axis Travel 5.9"
Z-1 Axis Travel 9.45"
Z-2 Axis Travel (Sub Spindle) 10.43"
Machine Dimensions (L x W x H) 79" x 47" x 66"
Machine Weight 3030 lbs.

FEATURES:
MITSUBISHI E60 CNC CONTROL
10.4" Color LCD
PC/MCIA Interface
Servo Driven Turret
Programmable Sub Spindle
Collet Chucks for Main & Sub Spindle
Chip Conveyor (Side Exit)
Three Color Tower Light
Fedek DH-65L S2 Servo Driven Short Magazine Barfeed
Auto Parts Catcher
Parts Exit Conveyor

세부내역

10.4" Color LCD
PC/MCIA Interface
Servo Driven Turret
Programmable Sub Spindle
Collet Chucks for Main & Sub Spindle
Chip Conveyor (Side Exit)
Three Color Tower Light
Fedek DH-65L S2 Servo Driven Short Magazine Barfeed
Auto Parts Catcher
Parts Exit Conveyor
